Product Characteristics
1: Circuit design since the power section from the power module on the selection of high-quality, high import component selection stable and reliable devices of the same type can replace imported instruments.
2: Sonic's patented intelligence technology software for intelligent echo analysis, without any debugging and other special steps, this technology has a dynamic thinking, dynamic analysis capabilities.
3: Our company has a smart patented sonic technology, greatly improving the accuracy of the instrument, level accuracy of 0.3%, resistant to all kinds of interference waves.
This instrument is a non-contact instrument, not in direct contact with the liquid, and therefore low failure rate. Instrumentation offers a variety of installation, the user can through this manual instrument calibration.
4: All input and output lines of the instrument have lightning protection, short circuit protection.
Measurement range |
0~20m (other range can be customized, pls contact us for a quote if your range is different) |
Blind zone |
0.25 ~ 0.6m |
Accuracy |
0.3% (in standard conditions) |
Resolution |
1mm |
Pressure |
normal atmospheric pressure |
Instrument display |
4 LED display scene shows the level or spatial distance |
Analog output |
4-20MA |
Digital output |
RS485, Modbus protocol, or customized protocol |
Working voltage |
DC24V, AC220V can be customized, with lightning protection device |
Environment temperature |
-20C ~ 60C |
Protection class |
IP65 |
Our integrated ultrasonic level meter has the following options:
a: Teflon probe
b: AC220V power supply
c: Switch power attached
d: Relay output
e: Background light display
f: Installation bracket
g: Ultrasonic level gauge or ultrasonic material meter/gauge
h: RS485 protocol
i: Single column display instrument attached
g: with GPRS
k: For hight temperature working environment
